Description
Overview
The TP-Link TL-WN725N is a compact and efficient wireless USB adapter designed to upgrade your WiFi connection speeds up to 150Mbps, ideal for smooth video streaming and internet calls. Operating on the 2.4GHz band, it provides reliable coverage throughout your home. Its nano size allows you to plug it in and leave it connected without obstruction or inconvenience.
Technical Specifications
- Interface: USB 2.0
- LED: Status indicator
- Weight: 0.07 ounces / 2.1 grams (without packaging)
- Dimensions (W x D x H): 0.73 x 0.59 x 0.28 inches (18.6 x 15 x 7.1 mm)
- Antenna: Internal antenna
- Wireless Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
- Frequency: 2.400-2.4835 GHz
- Signal Rate: 11b: up to 11 Mbps (dynamic), 11g: up to 54 Mbps (dynamic), 11n: up to 150 Mbps (dynamic)
- Reception Sensitivity: 130M: -68 dBm @10% PER, 108M: -68 dBm @10% PER, 54M: -68 dBm @10% PER, 11M: -85 dBm @8% PER, 6M: -88 dBm @10% PER, 1M: -90 dBm @8% PER
- Wireless Modes: Ad-Hoc / Infrastructure mode
- Wireless Security: Supports 64/128 WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES), supports IEEE 802.1X
- Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
- Transmission Power: <20 dBm
- Certification: CE, FCC, IC, RoHS
- Package Content: 150Mbps Wireless N Nano USB Adapter TL-WN725N, Resource CD, Quick Installation Guide
- System Requirements: Windows 11/10/8.1/8/7/XP, Linux
- Environment: Operating Temperature: 0°C~40°C (32°F~104°F), Storage Temperature: -40°C~70°C (-40°F~158°F), Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing
Source: TP-Link official page
