TP-Link TL-WPA7517 KIT AV1000 Gigabit Powerline ac Wi-Fi Kit with 1GB Ethernet, Dual Band Wi-Fi

Overview

The TP-Link TL-WPA7517 KIT AV1000 Powerline Wi-Fi Kit provides a reliable solution to extend both wired and wireless networks throughout your home by utilizing your existing electrical wiring. This eliminates Wi-Fi dead zones and buffering issues, delivering seamless connectivity in every corner of your house. The kit includes two adapters: the TL-WPA7517 with dual-band Wi-Fi capabilities and a Gigabit Ethernet port, and the TL-PA7017 with a Gigabit Ethernet port for wired connections.

Supporting speeds up to 1000 Mbps over powerline and gigabit Ethernet, this kit ensures fast and stable network performance. The TL-WPA7517 adapter supports dual-band Wi-Fi with 300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz bands, enhancing wireless coverage and capacity. Additionally, the kit supports OneMesh™ technology, allowing you to create a flexible and unified mesh network with compatible TP-Link devices.

Technical Specifications

• Transmission Speeds: Powerline up to 1000 Mbps; Ethernet 10/100/1000 Mbps
• Transmission Distance: Up to 300 meters (1000 feet) over existing electrical wiring
• Standards and Protocols: HomePlug AV2, IEEE 1901, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b/g/n (2.4 GHz), IEEE 802.11a/n/ac (5 GHz)
• Compatibility: Compatible with all HomePlug AV & AV2 standard powerline adapters
• Plug Type: EU
• Interfaces: TL-WPA7517: 1× Gigabit Ethernet Port; TL-PA7017: 1× Gigabit Ethernet Port
• Buttons: Pair, LED On/Off, Wi-Fi Clone, Reset
• Max. Power Consumption: TL-WPA7517: Max 11W, Typical 6.5W; TL-PA7017: Max 2.9W, Typical 2.6W
• LED Indicators: Power, Powerline, Ethernet, Wi-Fi (2.4 GHz), Wi-Fi (5 GHz)
• Wireless Standards (TL-WPA7517): IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ax 2.4 GHz
• Frequency (TL-WPA7517): 2.4 GHz and 5 GHz
• Signal Rate (TL-WPA7517): 300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz
• Mesh Technology: OneMesh™ Supported
• Security: Powerline: 128-bit AES Encryption; Wireless: WPA-PSK / WPA2-PSK, WEP Encryption
• Management Features: TP-Link tpPLC App and tpPLC Utility for PC
• Modulation Technology: OFDM (PLC)
• Network Services Enabled by Default: Web Server (HTTP/HTTPS), DHCP Server, OneMesh Management, App Management with specified ports and protocols
• Dimensions (W×D×H): TL-WPA7517: 2.7 × 1.4 × 4.9 in (69.5 × 35 × 124.1 mm); TL-PA7017: 2.0 × 1.1 × 2.6 in (52 × 28.5 × 65 mm)
• Package Content: AV1000 Powerline Wi-Fi Kit (TL-WPA7517 & TL-PA7017), 2× Ethernet Cables, 1× Quick Installation Guide
• Certification: CE, RoHS
• System Requirements: Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux
• Environment: Operating Temperature: 0°C~40°C (32°F~104°F); Operating Humidity: 10%~90% non-condensing

Source: TP-Link official page
