TP-Link EAP772 BE11000 Tri-Band Wi-Fi 7 Access Point with 2.5G Port

Description

Overview

The TP-Link EAP772 is a high-performance ceiling mount access point based on the BE11000 tri-band Wi-Fi 7 platform. It delivers ultra-fast wireless speeds across three bands—2.4 GHz, 5 GHz, and 6 GHz—making it ideal for dense environments requiring robust connectivity. Featuring a 1× 2.5G Ethernet port, the EAP772 supports advanced wireless functions such as Multi-Link Operation (MLO), 4K-QAM modulation, MU-MIMO, and OFDMA to optimize network efficiency and user experience. Its ceiling, wall, or junction box mounting options provide flexible installation, while coverage extends up to 1500 square feet, supporting over 380 concurrent clients.

Technical Specifications

• Interface: 1× 2.5G Ethernet Port
• Button: Reset
• Power Supply: 802.3at PoE or 12V/2.5A DC (DC adapter not included; DC interface: 12V, 2.1 mm / 5.5 mm center-positive circular plug, 9 mm length)
• Max. Power Consumption: 25.4 W (PoE), 21.8 W (DC)
• Dimensions (W×D×H): 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)
• Antenna: 2.4 GHz: 2× 4.0 dBi; 5 GHz: 2× 5.0 dBi; 6 GHz: 2× 5.0 dBi
• Bluetooth: 1× 4.0 dBi, Bluetooth 5.2 (firmware update may be required)
• Mounting: Ceiling, Wall, Junction Box (kits included)
• Coverage: 1500 ft² (140 m²)
• Concurrent Clients: 380+
• Wireless Standards: IEEE 802.11 a/b/g/n/ac/ax/be
• Frequency Bands: 2.4 GHz, 5 GHz, 6 GHz
• Signal Rate: 688 Mbps (2.4 GHz) + 4324 Mbps (5 GHz) + 5765 Mbps (6 GHz)
• Wireless Functions: MLO, 4K-QAM, MU-MIMO, 320 MHz Bandwidth, Mesh, Seamless Roaming (802.11k/v/r), BSS Coloring, OFDMA, Load Balance, Band Steering, Beamforming, Airtime Fairness, Multiple SSIDs (24 total, 8 per band), Wireless Schedule, Reboot Schedule, QoS (WMM), Rate Limit, Static/Dynamic IP, RADIUS Accounting, MAC Authentication
• Wireless Security: Captive Portal Authentication, Access Control, MAC Filter (up to 4,000), Wireless Isolation, VLAN, Rogue AP Detection, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
• Transmission Power: < 25 dBm (2.4 GHz), < 25 dBm (5 GHz), < 23 dBm (6 GHz)
• Omada App Support: Yes
• Centralized Management: Omada Cloud-Based Controller, Hardware Controller, Software Controller
• Cloud Access: Yes (requires Omada controller)
• Email Alerts: Yes
• LED Control: On/Off control available
• Management MAC Access Control: Yes
• SNMP: v1, v2c, v3
• System Logging: Local and Remote Syslog supported
• Web-based Management: Yes
• Certification: CE, FCC, RoHS, IC
• Package Contents: Omada Ceiling Mount Access Point EAP772, Installation Guide, Ceiling/Wall/Junction Box Mounting Kits
• Environment: Operating Temperature: 0 °C–40 °C (32 °F–104 °F); Storage Temperature: -40 °C–70 °C (-40 °F–158 °F); Operating Humidity: 10%–90% non-condensing; Storage Humidity: 5%–90% non-condensing

Source: TP-Link official page
