InSight S385PI VIGI 8MP Outdoor IR Panoramic Bullet Network Camera with 8MP Sensor, 1.65mm Lens

Overview

The InSight S385PI is a high-resolution 8MP outdoor IR panoramic bullet network camera designed to provide comprehensive surveillance coverage for your business. Featuring a 1/2.7” Progressive Scan CMOS sensor and a fixed 1.65 mm focal length lens, it delivers a wide 180° horizontal field of view, ideal for monitoring large areas with minimal blind spots. The camera supports advanced IR illumination up to 20 meters, ensuring clear images even in low-light or nighttime conditions.

Equipped with built-in microphone and speaker, the camera enables two-way audio communication, enhancing security and interaction capabilities. It supports on-board storage via a MicroSD card slot with capacity up to 512 GB, allowing local video recording. The device is built with robust metal housing, rated IP67 for weatherproofing and IK10 for vandal resistance, making it suitable for harsh outdoor environments.

Technical Specifications

• Image Sensor: 1/2.7” Progressive Scan CMOS
• Shutter Speed: 1/3 to 1/10000 s
• Minimum Illumination: 0.005 Lux; 0 Lux with IR Light
• Lens: Fixed Focal Length 1.65 mm, Aperture F2.0
• Field of View (FOV): Horizontal 180°, Vertical 86°, Diagonal 180°
• IR LED: 4 LEDs, Range 20 m (65.62 ft), Wavelength 850 nm
• Resolution: Up to 3840 x 2160 (8MP)
• Video Compression: Main Stream H.265+/H.265/H.264+/H.264; Sub-Stream H.265/H.264
• Frame Rate: Up to 30 fps depending on resolution and rotation
• Audio: Two-Way Audio with Built-in Microphone and Speaker; Audio In/Out Interfaces; 8 KHz sampling rate; 64 Kbps (G.711 alaw)
• Network Interface: 1 RJ45 10/100M Ethernet Port with PoE (802.3at, Class 4)
• Storage: MicroSD card slot supporting up to 512 GB
• Protection: IP67 Weatherproof, IK10 Vandal Proof
• Operating Temperature: -30 °C to 60 °C (-22 °F to 140 °F)
• Operating Humidity: 95% or less (non-condensing)
• Dimensions: 10.5 × 3.9 × 4 in (266 × 100 × 101 mm)
• Weight: 1.01 Kg
• Power Supply: 12V DC ± 5%, Max 18W; PoE 802.3at, Max 21W
• Smart Features: Intrusion Detection, Line-Crossing Detection, Region Entering/Exiting, Object Abandoned/Removal, Loitering, People and Vehicle Detection, Abnormal Sound, Scene Change
• Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
• Compatibility: ONVIF Profile S/T/G, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client
• Package Includes: VIGI Network Camera, Quick Start Guide, Waterproof Cable Attachments, Mounting Accessories
• Certifications: CE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, ONVIF

Source: TP-Link official page
