Description
Overview
The TP-Link Tapo S220 is a smart light switch designed for convenient and efficient control of your lighting system. Featuring a 2-gang 1-way setup, it allows you to manage two separate circuits independently. This switch requires a hub for operation and supports wireless communication at 868 MHz, enabling seamless integration into your smart home network.
With a compact design measuring 87.1 Ã 86 Ã 41 mm, the Tapo S220 fits standard switch boxes and offers reliable performance with certifications including CE, RoHS, and UKCA. It supports various lighting loads including LED, CFL, incandescent, fluorescent tubes, and fans, making it versatile for different household applications.
Technical Specifications
- Hub Required: Yes
- Standby Power Consumption: 65uA
- Rating: 250 V~ 50/60 Hz 4 A (Each Gang)
- Max Load: 600 W LED / 600 W CFL / 1000 W INC / 1000 W FTL / 50 W Fan
- Wireless: 868 MHz
- Operating Temperature: 0ºC ~ 40ºC (32ºF ~ 104ºF)
- Operating Humidity: 10% ~ 90% RH, Non-condensing
- Dimensions (H Ã W Ã D): 87.1 Ã 86 Ã 41 mm
- Certifications: CE, RoHS, UKCA
- Package Content: Tapo S220, 2 Ã 1.5 V AAA/LR03 Batteries, 2 Ã Mounting Screws, Quick Start Guide
Source: TP-Link official page
