Description
Overview
The TP-Link JetStream TL-SG2210P is a 10-port Gigabit Smart Switch designed to deliver high-performance networking with advanced features. It includes 8 PoE+ ports compliant with 802.3af/at standards, providing up to 61 W power supply to connected devices. This fanless switch supports a variety of network protocols and offers flexible management options through the Omada Cloud-Based Controller and other Omada controllers.
Ideal for business environments, the TL-SG2210P supports VLAN, IPv6, Quality of Service (QoS), and advanced security features to ensure efficient and secure network operation. Its compact design allows for desktop or wall mounting, making it versatile for different installation needs.
Technical Specifications
- Standards and Protocols: IEEE 802.3i, 802.3u, 802.3z, 802.3ab, 802.3ad, 802.3af, 802.3at, 802.3x, 802.1d, 802.1s, 802.1w, 802.1q, 802.1p, 802.1x
- Interface: 8Ã 10/100/1000Mbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX), 2Ã 1000Mbps SFP Slots
- Network Media: 10BASE-T: UTP category 3, 4, 5 cable (max 100m); 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (max 100m); 1000BASE-X: MMF, SMF
- Fan Quantity: Fanless
- Power Supply: 100~240VAC, 50/60Hz; External Power Adapter (Output: 53.5VDC/1.31A)
- PoE Ports (RJ45): 8 ports, 802.3af/at compliant; Power Supply: 61 W*
- Dimensions (W x D x H): 8.2 x 4.9 x 1.0 in (209 x 126 x 26 mm)
- Mounting: Desktop / Wall-Mounting
- Max. Power Consumption: V3.2: 76.5 W (220 V/50 Hz) with 61 W PD connected; 10.3 W (no PD connected); V4: 74.4 W; V5: 77.8 W (110 V/60 Hz) with 61 W PD connected
- Max Heat Dissipation: V3.2: 261.02 BTU/hr with 61 W PD connected; 35.14 BTU/hr no PD connected; V4: 253.89 BTU/hr; V5: 265.3 BTU/hr (110 V/60 Hz)
- Packet Buffer Memory: 4.1 Mbit
- Jumbo Frame: 9 KB
- Switching Capacity: 20 Gbps
- Packet Forwarding Rate: 14.88 Mpps
- MAC Address Table: 8K entries
- Quality of Service: 802.1p CoS/DSCP priority, 8 priority queues, SP and WRR scheduling, queue weight configuration, bandwidth control, storm control for broadcast/multicast/unknown-unicast
- Advanced Features: Automatic device discovery, batch configuration and firmware upgrading, intelligent network monitoring, abnormal event warnings, unified configuration, reboot scheduling
- VLAN: Supports up to 4K VLAN groups, 802.1Q tag VLAN, MAC VLAN (12 entries), protocol VLAN, GVRP, voice VLAN
- IPv6 Support: Static routing and ACL, dual IPv4/IPv6, interface, MLD snooping, neighbor discovery, MTU discovery, ICMPv6, TCPv6/UDPv6, DHCPv6 client, Ping6, Tracert6, Telnet(v6), SNMP, SSH, SSL, HTTP/HTTPS, TFTP
- MIBs: MIB II (RFC1213), Bridge MIB (RFC1493), P/Q-Bridge MIB (RFC2674), Radius Accounting and Authentication Client MIBs, Remote Ping and Traceroute MIB, TP-Link private MIBs, RMON MIB (RFC1757)
- Omada App Compatibility: Yes, via Omada Cloud-Based Controller, OC300, OC200, Omada Software Controller
- Centralized Management: Omada Cloud-Based Controller, OC300, OC200, Omada Software Controller
- Cloud Access: Supported through Omada Cloud-Based Controller, OC300, OC200, Omada Software Controller
- Zero-Touch Provisioning: Yes, requires Omada Cloud-Based Controller
- Management Features: Web GUI, CLI via telnet, SNMP v1/v2c/v3, SNMP Trap/Inform, RMON, SDM Template, DHCP/BOOTP Client, dual image/configuration, CPU monitoring, cable diagnostics, EEE, SNTP, system log
- Certification: CE, FCC, RoHS
- Package Content: TL-SG2210P, Power Adapter, Installation Guide, Rubber Feet
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista, 7/8/10/11; MAC OS; NetWare; UNIX; Linux
- Environment: Operating Temperature: 0°C~40°C (32°F~104°F); Storage Temperature: -40°C~70°C (-40°F~158°F); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing
Source: TP-Link official page
